VIDEO INPUT 视频输入

Panel Type

TFT LCD

Panel Size

-

Interface

Single/Dual LVDS

Max Resolution

1920*1080

CVBS

Video System

PAL

Video level

1.0 Vp-p±10%

HDMI

480i, 480p,576i,576p, 720p, 1080i, 1080p

HDMI/HDCP Version

1.4A/1.4

AUDIO INPUT

音频输入

CVBS

L/R RCA input

0.2 ~ 2.0 VRMS

AUDIO OUTPUT

音频输出

Frequency response

100Hz-15KHz @±3dB(1KHz 0dB reference signal)

Max output power

2×3W(4Ω) THD+N<10%@1KHz

(Power Supply:12V,Audio Input:0.5VRMS)

POWER  TO PANEL

驱屏电压

3.3V/5V/12V(±5%)

USB  FUNCTION USB   功能

软件升级，多媒体播放

software upgrade, multimedia play

按键类型

Button Types

对地按键接口

Button Interface to the ground
