CPU

RK3588 Quad-core Cortex-A76 and Quad-core Cortex-A55, up to 2.4GHz

DDR

LPDDR4 4GB (8GB|16GB|32GB optional)

Storage

The default comes with an 32GB EMMC NAND chip that can scale up to 256GB

HDMI Output

2 Micro HDMI 2.0 display interface supports up to 8K@60FPS output

HDMI Input

HDMI 2.0 standard video input interface supports 720P and 1080P signals

MIPI-DSI

2 way 31-Pin FPC MIPI-DSI display port supporting up to 1920x1200

MIPI CSI

2-way MIPI CSI interface, up to 16 megapixel MIPI camera support

HP/MIC

Support CTIA 4-pole HP/MIC socket (Left-Right-GND-Mic)

MIC Input

Single-End MIC input (pin header)

USB 2.0 Interface

6 USB horizontal connectors (2 USB2.0 and 4 USB3.0), 1 type-c OTG

Serial Port

1 1.25mm 3-pin built-in serial port

Micro SD Card

Self-elastic micro SD card socket, up to 256GB capacity

Built-in high performance SDIO interface WiFi module, support IEEE 802.11 b/g/n/ac/ax

Bluetooth

Built-in high performance UART interface BT module with support for V2.1+EDR/BT v3.0/BT v3.0+HS/BT v5.0

Ethernet

2-way 2.5G Adaptive Ethernet RJ45 connector

Fan Control

One FAN port

GPIO Interface

40pin 2.54mm pin: Supports I2S, CAN, I2C, UART, PWM, SPI, GPIO interfaces

M.2 PCIE NVME Port

1 Supports M.2 PCIE NVME SSDS, support for M.2 NVME 2280 SSDS

PCIe FPC

16pin PCIe 2.0 FPC port expands PCIe peripherals

Infrared remote control

Standard infrared remote control receiver

Real Time Clock

Ultra-low-power RTC circuit (CR1220 battery) with timer and alarm functionalities

LED Indicator

Blue LED indicator for running

Buttons

Recovery mode button, power switch button and reset button

DC Input

Supports 5V-2A voltage DC power input (type-c)

Ambient Requirement

Working temperature -20¡ãC ~ 70¡ãC, working humidity 0%~95% (non-condensing)

Physical Size

Length*Width*Height (100mm*100mm*21.5mm), PCB top side height 17.5mm

Operating System

Recommend android 12, optional android 13, Linux Buildroot / Debian 11 /Ubuntu 22.04 and Tongxin UOS

AOS-3588

AndroidRK3588 CPU£¬memory1G£¬  storage8G SSD

AndroidRK35588 CPU£¬memory2G£¬  storage16G SSD

AndroidRK35588 CPU£¬memory4G£¬  storage32G SSD
