OSD LANGUAGE OSD

English,Russian,Deutsch,Français,Español,Italiano,Hollands,Finnish,Turkish, Polish,Portuguese,Brazilian Portuguese,繁體中文,简体中文,日本語,한국어

PANEL

Panel Type

TFT LCD

Interface

2/4LAN eDP

VIDEO INPUT

HDMI

480i, 480p, 720p, 1080i, 1080p, 2160p

Max Resolution

2560*1440@165Hz

HDMI Version

2.0

DP

Max Resolution

2560*1440@165Hz

DP Version

1.4

AUDIO OUTPUT

Earphone

Earphone output

130 ~ 150mVRMS

Frequency response

Speaker

100Hz-15KHz @±3dB(1KHz 0dB reference signal)

Earphone

150Hz-15KHz @±3dB(1KHz 0dB reference signal)

Max Output power

2×2W(4Ω) THD+N<10%@1KHz
(Audio Input: 0.5VRMS)

POWER TO PANEL

3V,5V, 12V

最大电流小于 3A，供屏电流不得超过3A,瞬间电流不得大于3.5A

Management

Standby Power Consumption < 0.2W(Board Only) 待机功耗< 0.2W（仅主板）

Button Types

Ground Key Interface 对地按键接口

Note: Licenses involved in specifications above are supposed to be obtained by customers themselves. 注意：以上规格涉及 License 部分需要客户自己获取。
