CPU

RK3588 Quad-core Cortex-A76 and Quad-core Cortex-A55, up to 2.4GHz

DDR

LPDDR4 2GB (4GB|8GB|16GB|32GB optional)

Storage

The default comes with an 16GB EMMC NAND chip that can scale up to 128GB

LVDS

30-pin industry-standard dual LVDS supporting VESA/JEITA format up to 1080P output

MIPI-DSI

31-Pin FPC MIPI-DSI display port supporting up to 1920x1200

HDMI Output

1 HDMI 2.1 standard display interface supports up to 8K output

HDMI Input

HDMI 2.0/1.4b standard video input interface, 2.0 up to 2160p@60Hz and 1.4b up to 1080p@120Hz

EDP

20-pin industry-standard EDP supporting 1~4 lanes format up to 4K@60Hz output

VGA

Industry-standard DB-15 and 9-pin header VGA output up to 1080P

4K LCD

Industry-standard 4K LCD cable VBO display interface

Amplifier output

8 Ohm 6W Dual Audio Amplifier Output

Headphone Output

Stereo Headphone Output (Audio Jack)

MIC Input

Differential MIC input (Audio Jack)

USB Interface

4 horizontal connectors (USB Host 3.0x3 and OTG USB 3.0x1), 1 built-in vertical port USB 3.0, 7 pin headers (USB Hub 2.0x6 and USB Host 2.0x1 direct)

Serial Port

1 TTL, 2 TTL/RS-232/RS-485 compatible, 2 TTL/RS-232 compatible, 4 extended TTL/RS-232 compatible

Camera

Support USB camera within 8 million pixels

WIFI

Built-in high performance SDIO interface WiFi6 module, support IEEE 802.11 a/b/g/n/ac/ax, 2.4G/5GHz is configured by default.

Bluetooth

Built-in high performance serial interface BT module with support for V2.1+EDR/BT v3.0/BT v3.0+HS/BT v4.0/BT v5.0

Ethernet

1 port 10/100/1000M Adaptive Ethernet RJ45 connector + 4-Pin POE header

m-PCIE 4G

1 Industry standard m-PCIE 4G module interface

Backlight Control

2 port Industry standard LCD backlight control header for LVDS & EDP, support for backlight switch and brightness adjustment

GPIO Signals

Up to 8-way GPIO signals for such as GPIO buttons and/or 3.3V digital input/output

I2C Bus

I2C pin header for I2C capacitive screen and etc

Security Port

1 Tamper control port

CAN Bus

2 CAN pin headers for CAN Bus peripherals

m-SATA

1 Industry standard mSATA module interface

SATA

SATA HD

4 ways Standard SATA 3.0 hard disk port with power supply header

Hard Disk Socket

1 way 64Pin splint PCIE hard disk socket X4 (optional)

Real Time Clock

Ultra-low-power RTC circuit (CR1220 battery) with timer and alarm functionalities

LED Indicator

Red LED indicator for standby and green LED indicator for running

Fan Header

SYS fan power and CPU fan power

Buttons

Recovery mode button£¬power switch button and reset button

DC Input

Supports 9~15V wide voltage DC power input

Ambient Requirement

Working temperature -20¡ãC ~ 70¡ãC, working humidity 0%~95% (non-condensing)

Physical Size

Length*Width*Height (170mm*170mm*17mm), PCB top side height 15.5mm

Operating System

Recommended Android 12.0,Linux QT/Ubuntu-20.04/Debian 11 optional
