AOS-M3N1002L2HM
Product introduction£º
Specifications
Processor/Chipset | Intel Alder Lake-N N100/N95/N97/N150/N305 CPU |
Memory | 1*DDR5 4800MHz single-channel memory slot , max. board support16GB 1*SIM |
LAN | 2* LAN£¨Intel i210 AT Gigabit LAN) |
Display | 2*HDMI 1*VGA(header) 1*LVDS , supports synchronous or asynchronous display |
Audio | 1*AUDIO (headset combo) |
Storage | 1*SATA3.0 1*M.2 NVME |
Expansion Slot | 1*Mini PCIe (supportsWI FI/4G/Bluetooth module) |
USB | 4*USB3.0 2*USB2.0 £¬4*USB2.0 |
COM | 6*COM£¨COM1-2 supports RS232/485/422£© |
Other Interfaces | 1*FP 1*GPIO 1*TPM 2*7Pin 1*SPK_CON 1*CPUFAN(back of board) |
Watchdog Timer | 0-255S , system reset |
Power Specifications | Wide voltage12-36Vinput |
Temperature | Storage Temperature: -20¡æ -70¡æ Operating Temperature: -20¡æ -60¡æ |
Dimensions | 148mm*102mm |
Sales Model | Description |
AOS-M3N1002L2HM | N95£º4 cores 4 threads, base 1.7GHz, turbo 3.4GHz£¬TDP15W N97£º4 cores 4 threads, max turbo 3.6GHz£¬TDP12W N100£º4 cores 4 threads, base 0.9GHz, turbo 3.4GHz, ultra-low 6W power consumption N150£º4 cores 4 threads, base 1.8GHz, turbo 3.6GHz£¬TDP12W N305£º8 cores 8 threads, base 1.6GHz, turbo 3.8GHz |
Applications
Suitable for education, restaurants, hotels, shopping malls, corporate meetings,government information disclosure, and other fields.
