chip set

SOC

internal storage

capacity

2GB SO-DIMM DDR42166 MHz memory ,  Max.8 GB

memory

EMMC

TF Card

M.2

SATA

16G,  Max.64GB

Support 64G

Support 128G

Support for group 1 ¨C 6 of SATA

show

chip set

output

import

CPU integrated graphics card HD Graphics

HDMI + HDMI single display, double display (same / asynchronous display)

1 HDMI (Max supported resolution: 3840x2160)

1 HDMI (maximum supported resolution: 1920x1080)

1 XHDMI IN (Max supported resolution: 1920x1080)

function

MINI PCIE

COM mouth

LVDS

power amplifier

GPIO

CAN

1X MINI PCIE(3G/4G)

2X RS232 + 1X RS485 (optional)

1X LVDS

5W

1X 4 in and 4 out of the GPIO

2 X CAN

network

network

WIFI

110 / 100 / 1000M electrical port network (2 group RJ45 LAN optional)

110 / 100 / 1000M Fiber (2 group fiber networks optional)

1 x WIFI2.4G/5G dual-mode + BT (optional) / WIFI6 is optional

I/O

USB 2.0

USB 3.0

IR

Power button

Reset

OPS joggle

LED lamp

DC JACK

audio frequency

2 USB2.0 (up to 3 groups)

2x USB3.0 (support up to 4 optional groups)

1 XIR infrared

1 ¡Á power button

1 Adventitia upgrade

1 OPS interface (80pin)

1 xLED indicator lamp

1 ¡Á DC JACK

1 ¡Á LINE-OUT & MIC-IN

source

import

rated dissipation

DC  12~19V

20W

Physical parameters

size

180mm (L) x 119mm (W)x30mm(H)

environment

temperature

humidity

Operating temperature: 0¡ãC ~50¡ãC Storage temperature: -20~70¡ãC

5%~90% with no condensation

operating system

edition

Android 11/ubuntu/  Linux

AOS-SOR35216G

RK3568 2.0 GHz 2G memory 16G EMMC

AOS-SOR35416G

RK3568 2.0 GHz 4G memory 16G EMMC

AOS-SOR35432G

RK3568 2.0 GHz 4G memory 32G EMMC

AOS-SOR358128G

RK3568 2.0 GHz 8G memory 128G EMMC
