AOS-SEFT210C17Y
Product introduction£º
Product introduction
Domestic embedded fanless industrial computer
Domestic Feiteng E2000Q
Support onboard 4/8/16GB DDR4 memory
Support dual storage mSATA/NVMe+SATA
Support 10xRS232\4xUSB3.0
Support 2xLAN Gigabit network card, 1xGPIO (8I/8O) (optional 16I/160)
Support 1x national secret security module (optional)
Support network wake-up, power-on, watchdog, etc.
The product complies with CE FCC ROHS specifications
Specification
Processor | CPU | E2000Q£¬2x2.0GHz+2x1.5GHz(2x1.8GHz+2x1.5GHz) |
Chipset | Intel® SOC | |
Memory | Capacity | 4/8/16GB onboard |
Storage | M.2 | 1xSATA3.0,1xM.2-2280NVMe,1xmSATA |
Display | Output | VGA0+VGA1/HDMI |
cache | L2 cache | 2M+256KB |
IO | expansion slot Ethernet USB Audio serial port encrypt GPIO electromagnetic compatibility | 1xmini-PCIe(SIM card slot) +1xmini-PCIe(x2 signal) 2x10/100/1000M adaptive 4xUSB3.0 1xLine out,1xMIC-in 10xRS232 2x13 needle arrangement 8 optocoupler isolation I/8 relay isolation O (optocoupler isolation 16I/16O) Classs B complete machine |
Power supply | Input | AC220 (standard ATX power supply) |
Environment | Working temperature Industrial humidity | 0-50 C (optional-40-85 C) 0-95%RH, noncondensable |
Physical parameters | Dimensions | 287mm¡Á220mm¡Á94mm |
Operating system | Version | With domestic operating systems such as Kylin, UOS, Yihui, Freeos and open source OS, you can choose 100% localization. |
dimensional drawing
Areas of application
Industrial computer, industrial tablet computer, self-service terminal, all-in-one machine, medical treatment, digital sign, POS cash register, etc.
