AOS-SX67A41ST3
Product introduction£º
Specification parameters
processor | CPU | Zhaoxin KX-U6780A (8-core 8-thread processor, 2.7GHz clock speed, 8MB L2 cache, 16nm architecture, 70W power consumption) |
chip set | Intel® SOC | |
BIOS | The 32Mbit AMI supports diskless boot, network wake-up, power-on boot, watchdog, and other features. | |
internal storage | capacity | 4GB SO-DIMM DDR4 2666MHz memory , Max.32GB |
memory | SATA joggle MINI PCIE M.2 |
1X m.2 PCIE 128G M.2 SSD NVME |
show | chip set output
| CPU integrated graphics HD Graphics VGA+HDMI single display, dual display (synchronous/asynchronous) 1 ¡Á VGA (maximum resolution: 1920¡Á1080) 1 ¡ÁHDMI (Supports up to 4096x2304 resolution)
|
network | slug WIFI | 1 ¡Á 10/100/1000M£¨RJ45 LAN£© 1 x WIFI Module support 802.11b/g/n £¨M.2 PCIE half card£© |
I/O | USB 3.0 USB 2.0 COM Power button LED lamp DC JACK audio frequency | 2x USB3.0 4¡Á USB2.0 1x COM (Optional) 1 ¡Á power button 1 x power indicator light & 1x hard drive indicator light 1 ¡Á 12-19V DC JACK 1 ¡Á LINE-OUT & MIC-IN |
source | import rated dissipation | DC 12-19V 90W |
watchdog | output margin | Interrupt, system reboot Level 255 Fixed Interval |
Physical parameters | size | 212mm (L) x 200mm (W) x 55mm (H) |
environment | temperature humidity | Operating temperature: 0¡ãC to 50¡ãC Storage temperature: -20¡ãC to 70¡ãC 5%~90% No condensation |
operating system | edition | Kirin/UOS/Windows 10/Linux |
Order information
Sales model | explain |
AOS-SX67A41ST3
| KX-6000 U6780A 2.7GHz (8-core, 70W) 4GB RAM 128GB SSD
|
AOS-SX65841ST3 | KX-6000 U6580 2.5GHz (8-core, 70W) 4GB RAM 128GB SSD |
application area
Ideal for education, restaurants, hotels, shopping malls, corporate meetings, and government transparency initiatives.
