chipset

Intel® H610/B660/Q670

BIOS

AMI 32Mbit£¬upport diskless boot, network wake-up, power-on boot, watchdog and other functions

Memory

capacity

2*DDR4/DDR5 16GB , MAX  64G

Storage

SATA interface M.2 interface

2*SATA

1*M.2  500G SSD

Display

Chipset Output

HDMI/VGA/DP

Network

chip

2 ¡Á  10/100/1000M£¨RJ45 LAN£©

I/O

USB 3.0

USB 2.0

COM

HDMI

VGA

Audio

4x  USB3.0

4¡Á USB2.0

2¡Á COM RS232

1¡Á HDMI

1¡Á VGA

1 ¡Á LINE-OUT &  MIC-IN &1x LINE IN£¬Integrated 6-channel high-fidelity audio

Onboard functions

PCIE

1*PCIE3.0 X16

1*PCIE X8

4*PCIE X4

1*PCIE X1

1*PCI

Power supply

Input Rated power consumption

ATX  1*24Pin +1*8Pin

600W

Watchdog

output

interval

Interrupt, system restart

255 level timer interval

Physical parameters

size

430mm (L) x 250mm (W)  x 44.5mm (H)

Environment

temperature

humidity

Operating temperature: 0¡ãC ~50¡ãC Storage temperature: -20~70¡ãC

5%~90% non-condensing

Operating system

Version

Windows 10/Windows 11 / Linux

AOS-SSH61F165SU

Intel Core i5-13400   16GÄÚ´æ  500G SSD

AOS-SSH61I81SU

Intel Core i3-12100   8GÄÚ´æ  128G SSD

Intel Core i3-13100   8GÄÚ´æ  128G SSD

Intel Core i3-14100   8GÄÚ´æ  128G SSD

AOS-SSH61F81SU

Intel Core i5-12400   8GÄÚ´æ  128G SSD

Intel Core i5-13400   8GÄÚ´æ  128G SSD

Intel Core i5-14400   8GÄÚ´æ  128G SSD

AOS-SSH61J81SU

Intel Core i7-12700   8GÄÚ´æ  128G SSD

Intel Core i7-13700   8GÄÚ´æ  128G SSD

Intel Core i7-14700   8GÄÚ´æ  128G SSD

AOS-SSH61X81SU

Intel Core i9-12900   8GÄÚ´æ  128G SSD

Intel Core i9-13900   8GÄÚ´æ  128G SSD

Intel Core i9-14900   8GÄÚ´æ  128G SSD
