AOS-SEHUI41S2L6C
Product introduction：
Specification
CPU | Intel® Haswell-U I3 4010U Dual-Core 1.7GHz CPU on board |
RAM | 1×SODIMM 4G,support DDR3 1066/1333/1600MHz 8GB max. |
Storage | 1×MSATA 128G SSD |
1×SATA HDD | |
Display | 1×VGA/1×HDMI output, support synchronous/asynchronous dual display function |
Networking | 2×Intel I211 1000M NIC chip, PCI-E bus Gigabit LAN card |
1×MINI PCI-E interface, support wireless network (WIFI) or 3G | |
COM | 6×COM RS-232 (optional 2*RS485) |
Front Panel I/O | 6×COM, 6×USB, 1×power switch |
Rear Panel I/O | 1×VGA , 1×HDMI/2,1×front audio ,4×RJ45 |
1×DC_IN | |
Chassis Material | Aluminum Alloy |
Surface treatment | Oxidized surface |
Heat Dissipation | Fanless chassis with integrated heat dissipation |
Power Supply | Dc12V power supply |
Mounting | Flat, Wall Mount |
Dimension | 218mm(L)×200mm(W)x56mm(H) |
Working Temperature | 0~50℃ |
Storage Temperature | -40~75℃ |
Ambient Humidity | 5~90% Air Humidity, Non-Condensing |
Operating System | Windows XP / Windows 7 / Windows 8 / Linux |
Ordering Info
Sales Model | Description |
AOS-SEHUI41S2L6C | Intel I3 4010U 1.7 GHz 4G RAM 128G SSD |
AOS-SEHUF41S2L6C | Intel I5 4200U 1.6 GHz 4G RAM 128G SSD Intel I5 5300U 2.3 GHz 4G RAM 128G SSD |
AOS-SEHUJ41S2L6C | Intel I7 4500U 1.8 GHz 4G RAM 128G SSD |
Areas of application
Suitable for visual inspection, industrial automation, self-service terminals, industrial robotic equipment, etc.
