Processor

CPU

Intel® I5 1235U

12th/13th Gen CoreTM i3, i5, i7 15W~35W processor

Chipset

Intel® SOC

BIOS

AMI 32Mbit, supports diskless boot, Wake-on-LAN, auto power-on, watchdog, etc.

Memory

Capacity

8G DDR4

2*DDR4 SODIMM memory slots, up to 64GB

Storage

SATA Interface

M.2 Interface

1*SATA3.0, supports SATA/NVME protocol SSD

 1*M.2  256G SSD 2280 interface

Display

Chipset

Output

CPU integrated graphics HD Graphics

Dual-screen synchronous display; HDMI/VGA/LVDS

Network

Chipset

WIFI/4G

1 ¡Á  10/100/1000M (1¡ÁRJ45 LAN, optional 2*RJ45)

1 x WIFI/3G/4G

I/O

USB 3.0

USB 2.0

HDMI

COM

DC JACK

Audio

2x  USB3.0 (single LAN optional: 4¡Á USB3.0)

2x USB2.0

1¡Á HDMI/VGA

1 ¡Á COM

1 ¡Á DC JACK port

1 ¡Á LINE-OUT &  MIC-IN

Onboard Functions

COM Port

USB2.0

LPT

Expansion Bus

1*RS232 (optional: 6*COM/RS232/485/422)

4 ¡Á 2*5N9Pin Header, expands to 2-4 groups of *USB2.0

1*JLPT (optional)

1*JGPIO, wide-voltage module....

Power

Input

Rated Power

DC JACK 12V

60W

Watchdog

Output

Interval

Interrupt, system restart

255-level fixed timing interval

Physical Parameters

Overall Dimensions

Cutout Dimensions

Package Dimensions

526.6mm x 319.2mmx63.7mm

518.6mm x311.2mm xR8.0

564mm x358mmx106mm

Environment

Temperature

Humidity

Operating Temperature: 0¡ãC ~50¡ãC   Storage Temperature: -10~60¡ãC

5%~90% non-condensing

Operating System

Version

Windows 10/Windows 11/ Linux

AOS-SPAUF82S21Z

CPU: I3-1220P  Clock: 3.1GHz  8G+128G

CPU: I5 1235U  Clock: 2.3G    8G+256G

CPU: I3-1315U  Clock: 3.0GHz  16G+256G

CPU: I5-1235U  Clock: 2.5GHz  8G+256G

CPU: I5-1340P  Clock: 2.7GHz   8G+128G

CPU: I7-1260P  Clock: 2.1GHz    8G+256G

CPU: I7-1360P  Clock: 2.2GHz   16G+256G
