AOS- SMVNC3568L1

Product introduction：

Scope of Application

AOS-SMVNC3568L is an industrial control host that is widely used in smart display terminal products, video terminal products, and industrial control terminal products, such as NAS platforms, smart vending machines, vision cabinets, routers, and firewalls.

Product Overview

AOS-SMVNC3568L adopts the Ruixin Micro RK3568 quad core processor, with a clock speed of up to 2.0GHz. Built in independent NPU with computing power up to 1Tops. Supports dual screen display of HDMI and VGA. The host is equipped with 6 independent gigabit network ports, which have excellent data processing and network throughput capabilities.

Product Features

◆ Supports 6-way independent 10/100/1000M adaptive Ethernet;

◆ Supports up to 8GB of memory;

◆ Built in neural network NPU, supporting 1Tops computing power;

◆ 8 USB interfaces, 1 RS232 (optional TTL);

◆ Supports dual screen display, with HDMI up to 4K resolution and VGA up to 1080P resolution;

◆  Supports WiFi6, Bluetooth V5.0, and 4G full network connectivity (optional);

◆  Perfectly supports various mainstream touch screens such as infrared, capacitor, resistor, etc., and supports mainstream peripheral drivers;

◆ Support Android system customization and provide system call interface API reference code.

Operating System

Android system: Recommended Android 11.0

Linux system: optional Ubuntu 20.04, Debian 10, Linux QT

Open source HarmonyOS: optional OpenHarmony 3.2

Product hardware index

Main hardware specifications
Dimensions	235*175.1*44mm
CPU	Ruixin Micro RK3568, quad core Cortex-A55, with a maximum frequency of 2.0GHz
GPU	Mali-G52 2EE
NPU	Supports up to 1Tops of computing power
DDR	Standard 2GB LPDDR4, optional 4GB/8GB
Flash	Comes standard with 16GB, supports up to 128GB
HDMI	1 channel, supporting up to 4K resolution
VGA	1 channel, supporting up to 1080P resolution
headset	1-way, three-stage 3.5mm headphone jack
microphone	1 channel, 3.5mm microphone socket
USB Host	4 USB 3.0, 4 USB 2.0
USB OTG	1 USB OTG
Serial port	1 RS232 (optional TTL)
mSATA	Built in 1 mSATA interface, supporting standard mSATA hard drives
Ethernet	6-way, 10/100/1000M adaptive Ethernet
WiFi frequency	2.4G&5G dual band
WiFi， Bluetooth	WiFi6， Bluetooth V5.0
WiFi antenna	1 piece
4G antenna	1 piece (optional)
RTC real-time clock	support
Timed power on/off	support
system upgrade	Support local USB upgrade
relative humidity	0%~95% (non condensing)
operation temperature	-20℃~70℃
power supply	9V~15V wide voltage DC (optional 18V~52V)

dimension：
