AOS-SISUI41SB.
Product introduction£º
Specification parameter
processor
| CPU | Intel Skylake-U I3 6100U 2.3GHZ Dual core and four threads (I3 6100U/I5 6200U/I7 6500U) |
chipset | Intel® SOC | |
BIOS | AMI 32Mbit£¬Supports disk-free startup, network wake up, power-on, and watchdog functions | |
Internal memory | capacity | 4GB SO-DIMM DDR4 2133 MHz memory , Max.16GB |
store | M.2 Ports SATA interface | 128G SSD 1xSATA |
reveal | chipset exportation
| CPU Integrated Graphics HD Graphics 520 HDMI+HDMI+VGA Single display, dual display, three display (same/asynchronous display) 1 ¡ÁHDMI (Max support resolution: 3840x2160 30HZ) 1 ¡ÁHDMI (Max support resolution: 3840x2160 60HZ) |
network | Chip WIFI | 2 ¡Á RTL8111H 10/100/1000M£¨RJ45 LAN£© 1 x WIFI Module support 802.11b/g/n £¨M.2 half card£© |
I/O | USB 3.0 USB 2.0 Power button Reset COM LED light DC JACK Audio frequency | 4x USB3.0 2¡Á USB2.0 1 ¡Á power button 1 ¡Á Reset button 1 ¡Á RJ45 COM£¨selectable 2COM£© 1x power indicator &1x hard disk indicator 1 ¡Á DC JACK 1 ¡Á LINE-OUT & MIC-IN, integrated 6-channel sound ALC662 sound card chip |
Power source | input Rated power consumption | DC 12~19V 45W |
Guard dog | exportation interval | The system restarts. Procedure 255 level timing interval |
Physical parameter | dimension | 104mm (L) x 154mm (W)x51mm(H) |
environment | temperature humidness | Operating temperature: 0¡ãC ~50¡ãC Storage temperature: -20 ¡ãC ~70¡ãC 5% to 90% no condensation |
Operating system | edition | Windows 10/Windows 7 / windows8 / Linux |
Ordering information
Sales model | Instructions |
AOS-SISUI41SB | Intel I3 6100U 2.30GHz 4Gmemory 128G SSD Intel I3 7100U 2.40GHz 4Gmemory 128G SSD |
AOS-SISUF41SB | Intel I5 6200U 2.30 GHz 4Gmemory 128G SSD Intel I5 7200U 2.50 GHz 4Gmemory 128G SSD |
AOS-SISUJ41SB | Intel I7 6500U 2.50 GHz 4Gmemory 128G SSD Intel I7 7500U 2.70 GHz 4Gmemory 128G SSD |
Areas of application
Suitable for education, restaurants, hotels, shopping malls, company meetings,government affairs and other areas.
