AOS-SISUI41SBM
Product introduction：
Specifications
processor | CPU | Intel Intel Skylake-U I3 6100U 2.3GHZ dual-core quad-threaded (I3 6100U/I5 6200U/I7 6500U) |
Chipset | Intel® SOC | |
BIOS | AMI 32Mbitsupports diskless startup, network wake-up, power-on power-on, watchdog, and more | |
memory | capacity | 4GB SO-DIMM DDR4 2133 MHz memory , Max.16GB |
storage | M.2 interface SATA interface | 128G SSD 1xSATA |
display | Chipset output
| CPU integrated graphics card HD Graphics 520 HDMI-VGA single-display, dual-display / display). 1 ×HDMI (maximum support resolution:3840x2160 30HZ). 1 ×VGA (maximum support resolution:1920x1080 60HZ). |
Internet | chip WIFI | 2 × RTL8111H 10/100/1000M（RJ45 LAN） 1 x WIFI Module support 802.11b/g/n （M.2 half card） |
I/O | USB 3.0 USB 2.0 Power button Reset COM LED light DC JACK audio | 4x USB3.0 2× USB2.0 (optional with ) 1 × power button 1 × Reset button 1 × RJ45 COM(optional 2COM). 1 x Power indicator light . . . 1x hard drive indicator light 1 × DC JACK 1 × LINE-OUT and MIC-IN with integrated 6-channel sound ALC662 sound card chip |
power supply | input Rated power consumption | DC 12~19V 350 |
Watchdog | output interval | Interruption, system restart 255-level timing interval |
The physical parameters | size | 128mm (L) x 128mm (W)x38mm(H) |
environment | temperature humidity | Operating temperature:0to50degreesC Storage temperature:-20 to 70degreesC 5% to 90% no condensation |
operating system | version | Windows 10/Windows 7 / windows8 / Linux |
Order information
Sales model | illustrate |
AOS-SISUI41SBM | Intel I3 6100U 2.30GHz 4G memory 128G SSD |
AOS-SISUF41SBM | Intel I5 6200U 2.30 GHz 4G memory 128G SSD |
AOS-SISUJ41SBM | Intel I7 6500U 2.50 GHz 4G memory 128G SSD |
Applications
Suitable for education, restaurants, hotels, shopping malls, corporate meetings, government affairs and other fields.
