Chipset

Intel® SOC

BIOS

AMI 32Mbit£¬ Support diskless boot, wake on LAN, power-on boot, the watchdog function

Memory

Capacity

4GB SO-DIMM 2xDDR4 2400 MHz memory ,  Max.32GB

Storage

SATA connector

M.2

2.5¨•HDD(optional)

1xM.2

display

Collective display

exportation
input

CPU Integrated graphics card Hypercore graphics card

HDMI+DP Single/double/three display (same/asynchronous/splicing display)

1 ¡ÁHDMI2.0B   £¨Maximum supported resolution£º4096x2304 60HZ£©

1X DP1.4 ((supported resolution£º4096*2304¡¢5120*2880¡¢7680*4320 60HZ)4K/5K/8K

Internet

Chip

WIFI

1 ¡Á   10/100/1000M

1 x WIFI Module support 802.11b/g/n £¨M.2 PCIE half card£©

I/O

USB 3.0

USB 2.0

Type-c

Power button

Reset

OPS connector

  COM

LED light

one-key reset

DC JACK

Audio

3x USB3.0

3¡Á USB2.0

1x type-c

1 ¡Á power button

1 ¡Á Reset button

 1 ¡Á OPS connector£¨80pin£©

1 ¡Á RS232 COM£¨optional£©

            1 x Power indicator light & 1 x Hard drive indicator lights            1 x hardware system restore in one touch

1 ¡Á DC JACK

1 ¡Á LINE-OUT &  MIC-IN

Power supply

Input

Rated power consumption

DC  12~19V

90W

Watchdog

Output

Interval

Interrupts, system restart

255 time interval

Physical parameters

Dimensions

180mm (L) x 195mm (W)x30mm(H)

Environment

Temperature

Humidity

Working temperature£º0¡ãC ~50¡ãC    Storage temperature£º-20~70¡ãC

5%~90%  No condensation

Operating system

Version

Windows 10/Windows 11 / Linux

AOS-SOHTI41SE

Intel I3 1115G4   3.0GHz    4GDDR      128G SSD

AOS-SOHTF41SE

Intel I5 1135G7  2.4GHz    4GDDR      128G SSD

Intel I5 11300H  3.1GHz    4GDDR      128G SSD

AOS-SOHTJ41SE

Intel I7 1165G7   2.8GHz    4GDDR      128G SSD

Intel I7 11370H   3.3GHz    4GDDR      128G SSD
