Chipset

Intel® SOC

BIOS

AMI 32Mbit, Diskless boot, Networking  awakeing, Power-on boot, watchdog, ect

Memory

Capacity

4GB SO-DIMM 1xDDR4 2400 MHz memory ,  Max.32GB

Storage

SATA

M.2

2.5¨•HDD(Choice)

1X 128G SSD M.2 NGFF/NVME£¨Choice£©

Disply

Integrated graphics

Output

CPU Intel® UHD Graphics

2*HDMI+DP Single Disply,dual Disply,Triple Disply¡¢quad Disply£¨Synchronous/Asynchronous/Splicing Disply£©

2 ¡ÁHDMI2.0   £¨Max Support£º4096x2304 60HZ£©

1X DP1.4 Choice(4096*2304¡¢60HZ)4K

Internet

Lan

WIFI

1 ¡Á 10/100/1000M(Choice2*RJ45)

1 x WIFI Module support 802.11b/g/n £¨M.2 PCIE half card£©

I/O

USB 3.1

Type-c

Power button

OPS port

  COM

LED Light

One-click restore

DC JACK

Audio

3x USB3.1

1x  type-c(ChoiceRJ45 LAN)

1 ¡Á power button

1 ¡Á OPS Port£¨80pin£©

1 ¡Á RS232 COM£¨Choice£©

            1 x Power Light &1xHDDLight

            1 x One-click restore for the hardware system

1 ¡Á DC JACK

1 ¡Á LINE-OUT &  MIC-IN

Power

Input

Rated Power

DC  12~19V

45-90W

WatchDog

Input

Interval

Interrupt, system restart

255 time interval

Physical Parameters

Dimension

180mm (L) x 119mm (W)x30mm(H)

Environment

Temperature

Humidity

Working Temp: 0¡ãC ~50¡ãC, Storage Temp: -20~70¡ãC

5%~90% No Condensation

Operating

System

Version

Windows 10/Windows 11 / Linux

AOS-SON10041SC

CPU£ºN100     4G Memory      128G SSD

AOS-SON15041SC

CPU£ºN150     4G Memory      128G SSD

AOS-SON9741SC

CPU£ºN97      4G Memory      128G SSD

AOS-SON9541SC

CPU£ºN95      4G Memory      128G SSD

AOS-SON10541SC

CPU£ºN105      4G Memory      128G SSD

AOS-SON20041SC

CPU£ºN200      4G Memory      128G SSD

AOS-SON30041SC

CPU£ºN300      4G Memory       128G SSD

AOS-SON30541SC

CPU£ºN305      4G Memory       128G SSD
